Rabbit micro controller




TN001



RABBIT micro controller




System timer clock extension for Dynamic C library

Technical note

 This article is available for download in pdf-format here





Authors:        Gerhard Burger

Version:         1.0

Last update:   07.11.2005

File:

Attachments: no attachments

Current versions available on: www.burger-web.com

Table of versions

Version

Date

Remarks

1.0

6.1.2005

First version





Please check internet for updates www.burger-web.com




















Table of versions. 1

1          Overview.. 3

2          Introduction. 3

2.1.1     The goal 3

2.1.2     Example. 3

2.1.3     The Modification. 4

2.2        Modification step 1. 5

2.3        Modification step 2. 6

2.4        Modification step 3. 7

2.5        Modification step 4. 8

2.6        Modification step 5. 9

3          Compatibility and side effects. 9

4          Disclaimer. 10

4.1        Limited Warranty and Disclaimer of Warranty. 10

4.2        ACKNOWLEDGMENT. 10




1          Overview

This document outlines how to modify the ZWorld library vdriver.lib to implement a system timer clock with ms-resolution. The description starts with a short problem description, shows an easy example and outlines the necessary modification step by step.

2          Introduction

Some times it can be useful in a project to have an exact clock e.g. for capturing data with a time stamp. Having the Rabbit Micro Controller, a RTC with a resolution of 1 second is provided. Beyond that some timer variables as ms_timer, s_timer etc. are available with the Z-World libraries but what happens if an exact time stamp is needed. The modification can be done in around 30 Minutes.

2.1.1          The goal

The goal of this patch is to extend the system timer by a variable MS_TIMER_CLOCK for getting a clock with a resolution of 1ms. The MS_TIMER_CLOCK variable runs from 0 to 999 and is synchronized with the SEC_TIMER variable. The variable MS_TIMER_CLOCK has the type unsigned int.

2.1.2          Example

The example shows how to read the clock system clock variable having a time stamp with ms-resolution. The picture below shows the extension of the clock by the new timer value MS_TIMER_CLOCK.

The value can easily be read by the same way as the SEC_TIMER value. MS_TIMER_CLOCK is synchronized wit the SEC_TIMER value. A small example that shows the current SEC_TIMER value and MS_TIMER_CLOCK value is shown below.



Example program how to use the MS_TIMER_CLOCK variable

// Example program of modified vdriver.lib

// this program shows how to use the modified library vdriver.lib with the MS_TIMER_CLOCK value

// Author: Gerhard Burger

// Date: 6. November 2005

// Feedback: please over: www.burger-web.com

// Updates: www.burger-web.com

//

// program description

// first step: SEC_TIMRER value is inited by the Real time clock value (it is assumed that

// the RTC is inited with the right time value

// second step: program prints out the current second value (holding the time and date in

// a resolution of 1 second and print out the milliseconds

void main(void)

{

SEC_TIMER = read_rtc();           // initialize SEC_TIMER to new RTC

printf("System time is %d seconds and %d2 milliseconds\r\n",SEC_TIMER,MS_TIMER_CLOCK);

}



2.1.3          The Modification

Having a system timer clock with ms resolution the library vdriver.lib has to be modified. Changes have to be made on 5 positions in the vdriver.lib and around 30 minutes are needed.

All positions in the file are indicated with the label “@Modification, so that you can find them very easy.

Attached a small description of the five Modification steps


2.2         Modification step 1

Define an external shared unsigned int variable MS_TIMER_CLOCK. This variable can be accessed by the application.

Modification 1

extern char __TICK_COUNTER;

extern char __MS_COUNTER;

extern int __SEC_COUNTER;

extern unsigned int __MCOS_COUNTER;

extern unsigned int __MCOS_CNT_VAL;

extern shared unsigned long MS_TIMER;

extern shared unsigned long TICK_TIMER;

extern shared unsigned long SEC_TIMER;



// @MODIFICATION-------------------------------  22. November 2004 --------------------------------additional code for 1000 Hz counter

// Extension to the system clock to MS-TIMERS

// Modification 1 to 5

extern shared unsigned int MS_TIMER_CLOCK;



extern char  bios_intnesting;

extern char  bios_swpend;



/*** EndHeader */



char  bios_intnesting;

char  bios_swpend;

unsigned int __MCOS_COUNTER;

char  __TICK_COUNTER;

char __MS_COUNTER;

int __SEC_COUNTER;

shared unsigned long SEC_TIMER;

shared unsigned long MS_TIMER;

shared unsigned long TICK_TIMER;

unsigned int __MCOS_CNT_VAL;





// @MODIFICATION----------------------------------  22. November 2004 --------------------------------------------additional code for 1000 Hz counter

// Extension to system Clock to MS-TIMERS

// Modification 2 of  5

shared unsigned int MS_TIMER_CLOCK;



char pisr_inuse;



#if __SEPARATE_INST_DATA__

// This overwrites the periodic interrupt relay

#rcodorg periodic_intvec apply

#asm

      jp periodic_isr

#endasm

#rcodorg rootcode resume

#endif



#asm xmem nodebug

;



Figure 1: Modification step 1 (indicated in blue color)


2.3         Modification step 2

Define a shared unsigned int variable MS_TIMER_CLOCK. This variable holds the milliseconds for the system clock.

Modification 1

extern char __TICK_COUNTER;

extern char __MS_COUNTER;

extern int __SEC_COUNTER;

extern unsigned int __MCOS_COUNTER;

extern unsigned int __MCOS_CNT_VAL;

extern shared unsigned long MS_TIMER;

extern shared unsigned long TICK_TIMER;

extern shared unsigned long SEC_TIMER;



// @MODIFICATION-------------------------------  22. November 2004 --------------------------------additional code for 1000 Hz counter

// Extension to the system clock to MS-TIMERS

// Modification 1 to 5

extern shared unsigned int MS_TIMER_CLOCK;



extern char  bios_intnesting;

extern char  bios_swpend;



/*** EndHeader */



char  bios_intnesting;

char  bios_swpend;

unsigned int __MCOS_COUNTER;

char  __TICK_COUNTER;

char __MS_COUNTER;

int __SEC_COUNTER;

shared unsigned long SEC_TIMER;

shared unsigned long MS_TIMER;

shared unsigned long TICK_TIMER;

unsigned int __MCOS_CNT_VAL;





// @MODIFICATION----------------------------------  22. November 2004 --------------------------------------------additional code for 1000 Hz counter

// Extension to system Clock to MS-TIMERS

// Modification 2 of  5

shared unsigned int MS_TIMER_CLOCK;



char pisr_inuse;



#if __SEPARATE_INST_DATA__

// This overwrites the periodic interrupt relay

#rcodorg periodic_intvec apply

#asm

      jp periodic_isr

#endasm

#rcodorg rootcode resume

#endif



#asm xmem nodebug

;



Figure 2: Modification step 2


2.4         Modification step 3

Jump to calculation of MS_TIMER_CLOCK

Modification 3

   inc   (hl)                 ; 8

   jr    nz,.DoneTICK          ; 5

   inc   hl                   ; 2    this runs every 16384 s.

   inc   (hl)                 ; 8

.DoneTICK:



   ld    a,(__MS_COUNTER)     ; 9    this runs every 1/1024th s.

   add   a,250                ; 4

   ld    (__MS_COUNTER),a     ; 10



// @MODIFICATION------------------- 22. November 2004 ----------------additional code for 1000 Hz counter

;// Extension to system Clock to MS-TIMERS

; Modification 3 of 5



; früher   jr    nc, .Done_MS          ; 5     skip 6 times per 256 entries because  ;        (250/256)*1024 = 1000

   jr    nc, .Done_MS_TIMER_CLOCK  ; 5 skip 6 times per 256 entries because  ;                  (250/256)*1024 = 1000



   ld    hl,   MS_TIMER       ; 6    this runs 1000 time per s.

   inc   (hl)                 ; 8

   jr    nz,.Done_MS           ; 5

   inc   hl                   ; 2    this runs ~ every 32/125 s.

   inc   (hl)                 ; 8

   jr    nz,.Done_MS          ; 5

   inc   hl                   ; 2    this runs ~ every 8192/125 s.

   inc   (hl)                 ; 8

   jr    nz,.Done_MS          ; 5

   inc   hl                   ; 2    this runs ~ every 2097152/125 s.

   inc   (hl)                 ; 8

.Done_MS:





;@MODIFICATION------------------  22. November 2004 ------------------additional code for 1000 Hz counter

;Extension to system Clock to MS-TIMERS

; Modification 4 of 5

;

   ld    hl,  MS_TIMER_CLOCK  ; 6    this runs 1000 time per s. // load address of MS_Timer_CLOCK

   inc   (hl)                 ; 8                               // icnrement ms

   jr    nz,.Done_MS_TIMER_CLOCK   ; 5  Check overflow

   inc   hl                   ; 2    this runs ~ every 32/125 s.  if overflow

   inc   (hl)                 ; 8

.Done_MS_TIMER_CLOCK:

;-------------------------------------------------------------------------------------------------additional code for 1000 Hz counter



   ld    hl,TICK_TIMER+1      ; 6

   ld    h,(hl)               ; 5







Figure 3: Modification step 3


2.5         Modification step 4

Increment the MS_TIMER_CLOCK variable and set to zero on overflow



Modification 4

   inc   (hl)                 ; 8

   jr    nz,.DoneTICK          ; 5

   inc   hl                   ; 2    this runs every 16384 s.

   inc   (hl)                 ; 8

.DoneTICK:



   ld    a,(__MS_COUNTER)     ; 9    this runs every 1/1024th s.

   add   a,250                ; 4

   ld    (__MS_COUNTER),a     ; 10



// @MODIFICATION------------------- 22. November 2004 ----------------additional code for 1000 Hz counter

;// Extension to system Clock to MS-TIMERS

; Modification 3 of 5



; früher   jr    nc, .Done_MS          ; 5     skip 6 times per 256 entries because  ;        (250/256)*1024 = 1000

   jr    nc, .Done_MS_TIMER_CLOCK  ; 5 skip 6 times per 256 entries because  ;                  (250/256)*1024 = 1000



   ld    hl,   MS_TIMER       ; 6    this runs 1000 time per s.

   inc   (hl)                 ; 8

   jr    nz,.Done_MS           ; 5

   inc   hl                   ; 2    this runs ~ every 32/125 s.

   inc   (hl)                 ; 8

   jr    nz,.Done_MS          ; 5

   inc   hl                   ; 2    this runs ~ every 8192/125 s.

   inc   (hl)                 ; 8

   jr    nz,.Done_MS          ; 5

   inc   hl                   ; 2    this runs ~ every 2097152/125 s.

   inc   (hl)                 ; 8

.Done_MS:





;@MODIFICATION------------------  22. November 2004 ------------------additional code for 1000 Hz counter

;Extension to system Clock to MS-TIMERS

; Modification 4 of 5

;

   ld    hl,  MS_TIMER_CLOCK  ; 6    this runs 1000 time per s. // load address of MS_Timer_CLOCK

   inc   (hl)                 ; 8                               // icnrement ms

   jr    nz,.Done_MS_TIMER_CLOCK   ; 5  Check overflow

   inc   hl                   ; 2    this runs ~ every 32/125 s.  if overflow

   inc   (hl)                 ; 8

.Done_MS_TIMER_CLOCK:

;-------------------------------------------------------------------------------------------------additional code for 1000 Hz counter



   ld    hl,TICK_TIMER+1      ; 6

   ld    h,(hl)               ; 5





Figure 4: Modification step 4


2.6         Modification step 5

Set variable MS_TIMER_CLOCK to 0 if 999ms have been reached.

Modification 5

   jr    z,.DoneTimers        ; 5



   ld    hl,__SEC_COUNTER     ; 6

   xor   a,(hl)               ; 6

   ld    (hl),a               ; 6



;@MODIFICATION---------------  22. November 2004 --------------------additional code for 1000 Hz counter

; Extension to system Clock to MS-TIMERS

; Modification 5 to 5

;

   xor   a                    ; clear a

   ld    (MS_TIMER_CLOCK),a

   ld    (MS_TIMER_CLOCK+1),a

;-----------------------------------------------------------------------------------additional code for 1000 Hz counter



   ld    hl,SEC_TIMER         ; 6

   inc   (hl)                 ; 8    this runs ~ every 1 s.

   jr    nz,.DoneTimers       ; 5

   inc   hl                   ; 2

   inc   (hl)                 ; 8    this runs ~ every 256 s.

   jr    nz,.DoneTimers       ; 5



Figure 5: Modification step 5

3          Compatibility and side effects

I tested the modification on the libraries of the compiler versions:

  • Dynamic C 8.01
  • Dynamic C8.61 and
  • Dynamic C9.02

On all of them it works very fine, also in more complex projects. I have not detected any side effects.

4          Download

The modified library vdriver.lib of version 8.61 as described above can be downloaded on:



5          Installation

1.       Move to directory of Dynamic C compiler  /Lib

2.       Create a copy of vdriver.lib e.g. vdriver.lib_original

3.       Either do modification of vdriver lib as described or use the modified vdriver.lib that can be downloaded on www.burger-web.com

4.       run the sample program for test
